Log Milling Machinery Portable Sawmills
Log Milling Machinery Portable Sawmills yog ib qho kev daws teeb meem zoo rau ntoo zeb ua haujlwm.
Muaj nuj nqi
Log Milling Machinery Portable Sawmills yog ib qho kev daws teeb meem zoo rau ntoo zeb ua haujlwm.
Sawmill tshuab yog cov cuab yeej siv tshuab tsim nyog rau kev ua ntoo. Lub luag haujlwm tseem ceeb yog txiav ntoo rau hauv qhov xav tau loj thiab cov duab, uas tuaj yeem ua tau raws li qhov xav tau ntawm cov rooj tog tsim khoom, kev tsim kho, nkoj tsim thiab lwm yam haujlwm.
SAIB
|
Qauv |
HS 26 G |
HS 31 G |
HS 26 E |
HS 31 E |
|
Hwj chim |
Roj av 9HP (LIFAN, phau ntawv pib) |
Roj av 15HP (LIFAN, phau ntawv pib) |
Lub cev muaj zog 5.5KW |
Lub cev muaj zog 7.5KW |
|
Kev khiav tawm |
301cc ua |
420cc ua |
400V 50HZ 3 theem |
|
|
Txiav muaj peev xwm |
660 * 178 * 2794 hli |
790 * 178 * 2794 hli |
660 * 178 * 2794 hli |
790 * 178 * 2794 hli |
|
Ncej |
4pcs ib |
4pcs ib |
4pcs ib |
4pcs ib |
|
Hniav loj |
369 (2) * 34 * 0.9 hli |
396 * 34 * 0.9 hli |
369 (2) * 34 * 0.9 hli |
396 * 34 * 0.9 hli |
|
Standard khiav loj |
4000 × 900 hli |
4000 × 1030 hli |
4000 × 900 hli |
4000 × 1030 hli |
|
Ntim |
2080 × 570 × 830mm |
2150 × 570 × 830 hli |
2080 × 610 × 810 hli |
2150 × 610 × 810 hli |
|
Kev nyab xeeb txiav ceev |
13-15s/m |
13-15s/m |
||
|
Hniav ceev |
17m / min |
17m / min |
||
|
Cov hniav nyob deb |
22mm (086") |
22mm (086") |
||
|
Hniav log Dia. |
480 hli (18.8 ") |
480 hli (18.8 ") |
||
|
Dimension |
4064 * 1778 * 1800mm (160 "* 70" * 71") |
4064 * 1778 * 1800mm (160 "* 70" * 71") |
||
|
Qhov hnyav |
400/430 kg |
430/450 kg |
||
SAIB TRAILER
|
Qauv |
HST4-26 |
HST6-26 |
HST4-31 |
HST6-31 |
|
Trailer qag |
50 x 50 mm |
50 x 50 mm |
50 x 50 mm |
50 x 50 mm |
|
Trailer loj (L * W * H) |
3970 (+1000 hli drawbar) x 900x700mm |
6000 (+1000mm drawbar)x900x700mm |
3970 ({1}} hli drawbar) x 1030 x 700 mm |
6000 (+1000mm drawbar)x1030x700mm |
|
Trailer log nrog fenders |
165/70R13 |
165/70R13 |
165/70R13 |
165/70R13 |
|
Trailer loading peev |
1500 kg |
1500 kg |
1500 kg |
1500 kg |
|
Trailer teeb |
LED teeb khoom siv |
LED teeb khoom siv |
LED teeb khoom siv |
LED teeb khoom siv |
|
Trailer leveling jacks |
6 pcs |
8pcs ib |
6 pcs |
8pcs ib |
|
Trailer Pob Coupler |
2 "(50mm) |
2 "(50mm) |
2 "(50mm) |
2 "(50mm) |
|
Ua kom tiav |
Galvanized |
Galvanized |
Galvanized |
Galvanized |
|
Log loading ramp |
Max. 1350kg ib |
Max. 1350kg ib |
Max. 1350kg ib |
Max. 1350kg ib |
|
Log loading winch |
1200 lbs |
1200 lbs |
1200 lbs |
1200 lbs |
|
Qhov hnyav |
430kg ua |
4 70kg |
430kg ua |
4 70kg |
Lub taub hau txav nce thiab nqis raws galvanized steel channel ntawm ib qho yooj yim heev tig tes crank system. Cov hniav yog khaws cia lubricated los ntawm kev siv lub drip system. Qhov no tiv thaiv sap ntawm gumming li koj cov hniav.
Yuav siv sawmill li cas
1. Kev Npaj: Npaj cov ntoo uas yuav tsum tau ua thiab xyuas kom cov ntoo yuav tsis co lossis swb.
2. Kho: Kho cov saw hniav kom haum qhov siab thiab lub kaum sab xis.
3. Thauj ntoo: Muab cov ntoo txiav rau lub tshuab sawmill.
4. Pib: Pib cov txheej txheem txiav nrog ceev ceev.
5. Ua kom tiav: Tom qab txiav tiav, tua lub hwj chim.
Lub ntim yog ntim tsis tu ncua rau Log Milling Machinery Portable Sawmills, customized ntim yog muaj.
