Khoom
3 Tuj Pob Zeb Breaker
Hydraulic breaker yog ib tug haib percussion rauj haum rau ib tug excavator rau demolishing qhob vaj tse los yog pob zeb.
Muaj nuj nqi
Hydraulic Breaker yog dab tsi?
Hydraulic breaker yog ib tug haib percussion rauj haum rau ib tug excavator rau demolishing qhob vaj tse los yog pob zeb.
1. Mining: roob, mining, crushing, thib ob crushing
2. Metallurgy, slag tu, ladle furnace demolition, demolition khoom foundation lub cev tsis txaus siab
3. Railway: qhov, choj, roob nqes
4. Txoj kev loj: kho txoj kev loj, cement pavement tawg, foundation excavation
5. Municipal vaj: pob zeb crushing, dej, hluav taws xob, roj engineering kev tsim kho, kev hloov pauv ntawm lub nroog qub
6. Lub tsev: lub tsev qub demolition, reinforced pob zeb tawg
7. Lub nkoj hull nyob rau hauv mussels
8. Lwm yam: dej khov tawg, tawg cov xuab zeb vibrating
|
Qauv |
Chav tsev |
TSEEM CEEB |
|||||
|
HWM 400 |
HWM 450 |
HWM 530 |
HWM 680 |
HWM 750 |
HWM 850 |
||
|
Qhov hnyav (sab / sab saum toj / lub thawv) |
kg |
70/ 72/102 |
95/ 95/126 |
138/138/152 |
263/ 263/299 |
334/ 335/ 375 |
559/ 569/ 589 |
|
Hydraulic flow range |
litre/min |
15-25 |
20-30 |
25-50 |
40-70 |
50-90 |
60-100 |
|
Kev khiav hauj lwm siab |
kg/cm2 |
90-120 |
90-120 |
90-120 |
110-140 |
120-170 |
130-160 |
|
Kev cuam tshuam ntau zaus |
bpm ua |
800-1400 |
700-1200 |
600-1000 |
500-900 |
400-800 |
400-800 |
|
Txoj kab uas hla ntawm chisel |
mm |
40 |
45 |
53 |
68 |
75 |
85 |
|
Txoj kab uas hla ntawm hose |
nti |
1/2 |
1/2 |
1/2 |
1/2 |
1/2 |
1/2 |
|
Rov qab lub taub hau siab |
kg/cm2 |
12-16 |
16 |
16 |
16 |
16±0.5 |
16±0.5 |
|
Accumulator siab |
kg/cm2 |
/ |
/ |
/ |
/ |
/ |
/ |
|
Haum Carrier |
ton |
0.8-1.2 |
1.2-2.5 |
2.5-4 |
4-6 |
6-8 |
8-9.5 |
|
Qauv |
Chav tsev |
MEDIUM HOM |
HOM HOM |
||||
|
HWM 1000 |
HWM 1250 |
HWM 1400 |
HWM 1550 |
HWM 1650 |
HWM 1750 |
||
|
Qhov hnyav (sab / sab saum toj / lub thawv) |
kg |
761/866/ 861 |
1277/1308/1371 |
1774/2059/1866 |
2577/ 2745/ 2968 |
2751/ 3156/ 2916 |
3905/4057/ 3902 |
|
Hydraulic flow range |
litre/min |
80-110 |
90-120 |
120-180 |
180-240 |
200-260 |
200-260 |
|
Kev khiav hauj lwm siab |
kg/cm2 |
150-170 |
150-170 |
160-185 |
170-200 |
160-180 |
180-200 |
|
Kev cuam tshuam ntau zaus |
bpm ua |
400-650 |
350-650 |
350-500 |
300-450 |
250-400 |
200-350 |
|
Txoj kab uas hla ntawm chisel |
mm |
100 |
125 |
140 |
155 |
165 |
175 |
|
Txoj kab uas hla ntawm hose |
nti |
3/4 |
3/4 |
1 |
1 |
5/4 |
5/4 |
|
Rov qab lub taub hau siab |
kg/cm2 |
16±0.5 |
15-18 |
16±0.5 |
16±0.5 |
16±0.5 |
16±0.5 |
|
Accumulator siab |
kg/cm2 |
/ |
/ |
60 |
60 |
60 |
60 |
|
Haum Carrier |
ton |
10-15 |
15.5-18 |
18-26 |
27-36 |
30-40 |
35-45 |
Yuav ua li cas xaiv chisels?
Kev Tswj Xyuas Zoo
1. Cov khoom siv raw: Lub tshuab tag nrho yog ua los ntawm cov hlau uas muaj zog hnav-resistant, uas muaj zog thiab ruaj khov.
2. Blanking: Tag nrho cov txheej txheem ntawm CNC blanking thiab ua, lub tshuab yog ntau qhov tseeb thiab ruaj khov.
3. Riam: Kho tau thiab hloov tau, nws tuaj yeem muab faib ua ob lossis ntau dua folding daim hlau, uas yuav tsis ua rau cov cuab yeej puas thiab txaj muag ntawm cov khoom siv tsis zoo.
4. Accessories: Xaiv lub tshuab hluav taws xob tshiab txhua yam, cov roj twj tso kua mis tshiab thiab lub valve lub cev kom tiv thaiv txhua yam khoom cuav thiab kev hloov tshiab thib ob.
5. Cov menyuam txoj kev: Nruab nrog cov khoom hauv qab cov menyuam, uas tuaj yeem txav mus rau sab nraud thiab rau pem hauv ntej.
Cim npe nrov: Tuam Tshoj 3 tuj pob zeb breaker manufacturers, lwm tus neeg, Hoobkas
